480
| Nakamichi 480 | |||||||||
 |
 |
||||||||
|
Service Manual |
|||||||||
|
User Manual |
|||||||||
|
Catalogue |
|||||||||
| |
|||||||||
| Release year | 1979-1982 | Average price | 495$ | ||||||
| Display | Head Configuration | ||||||||
| Track Indicator | 2 Head Design | √ | |||||||
| Digital Peak-Reading Meters | 3 Head Design | ||||||||
| Mechanical Counter | √ | Seperate Record and Playback Heads | |||||||
| Analog Needle Meters | √ | 4 Track / 2 Channel | √ | ||||||
| Linear Tape Counter | |||||||||
| Tape | |||||||||
| Connectivity | Chrome Tape Capability | √ | |||||||
| Headphones | √ | Normal Tape Capability | √ | ||||||
| RCA Input/Output | √ | Metal Tape Capability | √ | ||||||
| Wired Remote Control | √ | Auto Tape Type Selection | |||||||
| Amp out | Manual Tape Type Selection | √ | |||||||
| Noise Reduction | Calibration | ||||||||
| Dolby-B Noise Reduction | √ | 15kHz Test Tone | |||||||
| Dolby-C Noise Reduction | 400Hz Test Tone | ||||||||
| Dolby-S Noise Reduction | Auto Playback Azimuth Correction | ||||||||
| DBX Noise Reduction | Manual Bias Calibration | ||||||||
| Double Dolby NR Circuits |
|
Manual Level Calibration | |||||||
| MPX Filter | √ | Auto Bias Calibration | |||||||
| Subsonic Filter | Auto Level Calibration | ||||||||
| Dolby HX Pro | |||||||||
| Indicators | |||||||||
| Transport | Record Indicator | √ | |||||||
| Pressure Pad Lifter | √ | Illuminated Cassette Compartment | |||||||
| Dual-Capstan Transport | √ | Chrome Tape | |||||||
| Auto Reverse | Metal Tape | ||||||||
| Belt Drive (Capstan) | √ | Normal Tape | |||||||
| Slack-Tape Takeup | √ | Fader Down | |||||||
| 2-Speed Cueing | Fader Up | ||||||||
| Mechanical Tape Loading | √ | ||||||||
| Speed | |||||||||
| Auto Shutoff | √ | 4.76 cm/s | √ | ||||||
| Double Direct Drive (Capstan) | 9.52 cm/s | ||||||||
| Idler Drive (Reel) | √ | ||||||||
| Multi Motor Mechanism | √ | ||||||||
| Belt Drive (Azimuth Adjustment) | |||||||||
| Belt Drive (Mechanism) | |||||||||
